5 x ON Semiconductor MC14052BCPG Multiplexer/Demultiplexer Supply Voltage 3V-18V - ON Semiconductor
roll over the image to zoom in
£0.00
£5.99
RS 519-0316
Unit Quantity:
5
Unit Type:
Unit
Location:
BRA 9D
ON Semiconductor
ON Semiconductor MC14052BCPG, Multiplexer/Demultiplexer Dual 4:1, 12 V, 15 V, 5 V, 9 V, 16-Pin PDIP
- BMUK Part # :-519-0316
- BrandON Semiconductor
- Mfr. Part No.MC14052BCPG
-
- You will get a pack of 5 ICs
Product Details
4000 Series Encoders/Decoders, Multiplexers/Demultiplexers, ON Semiconductor
4000 CMOS Logic Family, ON Semiconductor
CMOS Family devices
Wide operating voltage range: 3 to 18V
Specifications
| Configuration | Dual 4:1 | |
| Package Type | PDIP | |
| Mounting Type | Through Hole | |
| Typical Single Supply Voltage | 5 V, 9 V, 12 V, 15 V | |
| Switch Type | Analogue Multiplexer | |
| Pin Count | 16 | |
| Power Supply Type | Single | |
| Input Signal Type | Single Ended | |
| Output Signal Type | Single Ended | |
| Minimum Operating Temperature | -55 °C | |
| Maximum Operating Temperature | +125 °C | |
| Number of Channels per Chip | 2 | |
| Board Level Components | Y | |
| Length | 19.55mm | |
| Multiplexer Architecture | 4:1 | |
| Dimensions | 19.55 x 6.85 x 3.43mm | |
| Height | 3.43mm | |
| Maximum Power Dissipation | 500 mW | |
| Width | 6.85mm |
