5 x ON Semiconductor LM317 LM317D2TR4G, Single Linear Voltage Regulator, 1.5A - ON Semiconductor
roll over the image to zoom in
£0.00
£5.99
RS 688-9219
Unit Quantity:
5
Unit Type:
Unit
Location:
TS 38Q
ON Semiconductor
ON Semiconductor LM317 LM317D2TR4G, Single Linear Voltage Regulator, 1.5A Adjustable 1.2 → 37 V, 3-Pin D2PAK
- BMUK Part # :-688-9219
- BrandON Semiconductor
- Mfr. Part No.LM317D2TR4G
-
- You will get a pack of 5 Voltage Regulators
Product Details
LM317 Linear Voltage Regulator, ON Semiconductor
ON SemiconductorLM317 series is an adjustable Linear Voltage Regulator. The 3-terminal positive voltage regulator can offer an output current of 1.5A and more with an output voltage ranging between 1.2 to 37 V. The easy to use LM317 adjustable voltage regulator can be used in various applications such as on-card regulation and being utilised as a programmable output regulator it can be used as a precision current regulator by attaching a fixed resistor between the adjustment and output.
Output Voltage Range: 1.25 V to 37 V
Output Current: 1.5 A
Short circuit current limiting, Thermal protection, and Safe-area compensation
Floating Operation for High-Voltage Applications
Linear Voltage Regulators, ON Semiconductor
Specifications
| Output Voltage | 1.2 → 37 V | |
| Maximum Output Current | 1.5A | |
| Package Type | D2PAK | |
| Output Type | Adjustable | |
| Mounting Type | Surface Mount | |
| Maximum Input Voltage | 40 V | |
| Pin Count | 3 | |
| Minimum Operating Temperature | 0 °C | |
| Maximum Operating Temperature | +125 °C | |
| Number of Outputs | 1 | |
| Polarity | Positive | |
| Load Regulation | 0.5 % | |
| Dimensions | 10.24 x 9.35 x 4.57mm | |
| Length | 10.24mm | |
| Width | 9.35mm | |
| Line Regulation | 0.04 %/V | |
| Reference Voltage | 1.3V | |
| Height | 4.57mm | |
| Series | LM317 |
