5 x ON Semiconductor BC373RL1G NPN Darlington Transistor 1A, 80V, 3-Pin - ON Semiconductor
roll over the image to zoom in
£0.00
£5.99
RS 545-0034
Unit Quantity:
5
Unit Type:
Unit
Location:
TS 11Q
ON Semiconductor
ON Semi BC373RL1G NPN Darlington Transistor, 1 A 80 V HFE:8000, 3-Pin TO-92
- BMUK Part # :-545-0034
- BrandON Semiconductor
- Mfr. Part No.BC373RL1G
- You will get a pack of 5 Transistors, these are very rare and hard to get hold of now
Product Details
NPN Darlington Transistors, ON Semiconductor
Standards
Manufacturer Part Nos with S or NSV prefix are automotive qualified to AEC-Q101 standard.
Bipolar Transistors, ON Semiconductor
A wide range of Bipolar Transistors from ON Semiconductor, which includes the following categories:
Small-Signal Transistors
Power Transistors
Dual Transistors
Darlington Pairs
High-Voltage Transistors
RF Transistors
Bipolar/FET Transistors
Specifications
| Transistor Type | NPN | |
| Maximum Continuous Collector Current | 1 A | |
| Maximum Collector Emitter Voltage | 80 V | |
| Maximum Emitter Base Voltage | 12 V | |
| Package Type | TO-92 | |
| Mounting Type | Through Hole | |
| Pin Count | 3 | |
| Number of Elements per Chip | 1 | |
| Minimum DC Current Gain | 8000 | |
| Maximum Base Emitter Saturation Voltage | 2 V | |
| Maximum Collector Base Voltage | 80 V | |
| Maximum Collector Emitter Saturation Voltage | 1.1 V | |
| Maximum Collector Cut-off Current | 0.0001mA | |
| Maximum Operating Temperature | +150 °C | |
| Length | 5.2mm | |
| Dimensions | 5.2 x 4.19 x 5.33mm | |
| Height | 5.33mm | |
| Minimum Operating Temperature | -55 °C | |
| Width | 4.19mm |
