5 x Murata Trimmer Resistor, PVZ2A472C04R00, 1-Turn, 4.7kΩ ±30% 0.1W ±500ppm/°C - Murata
roll over the image to zoom in
£0.00
£5.99
RS 788-4228
Unit Quantity:
10
Unit Type:
Unit
Murata
Murata SMD Trimmer Resistor with Solder Pad Terminations, 4.7kΩ ±30% 0.1W ±500ppm/°C
- BMUK Part # :-788-4228
- BrandMurata
- Mfr. Part No.PVZ2A472C04R00
-
- You will get a pack of 5 Resistors
Product Details
2mm Open Frame PVZ2 Series
Ultra-small and thin external dimensions
Compact PCB design is possible by smaller adjustment hole (3.0mm dia.) due to short wing
length (4.8mm). (Rear adjustment type: PVZ2R_C04 Series)
Gold plated terminations
Cross-shaped driver slot permits in-process automatic adjustment and excellent
adjustability
High quality / low cost dual part build component construction
Suitable for high density PCB mounting and reflow soldering
RoHS compliant
Applications include: Pick-up modules; LCD’s; mobile phones; PHS; Pager; DVC; Digital camera; Portable audio; RKE; E-Book
Single Turn - Surface Mount - Carbon
Specifications
| Maximum Resistance | 4.7 kΩ | |
| Number of Turns | 1 | |
| Mounting Type | Surface Mount | |
| Power Rating | 0.1W | |
| Termination Style | Solder Pad | |
| Length | 2.1mm | |
| Depth | 2.2mm | |
| Height | 0.8mm | |
| Dimensions | 2.1 x 2.2 x 0.8mm | |
| Shaft Diameter | 2.4 mm | |
| Tolerance | ±30% | |
| Maximum Operating Temperature | +85°C | |
| Minimum Operating Temperature | -25°C | |
| Temperature Coefficient | ±500ppm/°C | |
| Board Level Components | Y |
