5 x Murata DSS6NC52A271Q93A, Signal Filter, Radial Termination, 100V dc, 6A - Murata
roll over the image to zoom in
£0.00
£5.99
RS 725-7297
Unit Quantity:
5
Unit Type:
Unit
Murata
Murata DSN6 Series, Signal Filter, 100 V dc, 6A Through Hole, Radial Termination, 8 x 2.54 x 7mm
- BMUK Part # :-725-7297
- BrandMurata
- Mfr. Part No.DSS6NC52A271Q93A
-
- You will get a pack of 5 Signal Filters
Product Details
Three Terminal Capacitors DSS6/DSS9 Series
Unlike conventional two terminal capacitors which have high residual inductance within the lead wires, thereby impeding the path of high frequency noise to ground, a three terminal capacitor forms a T-filter providing high inductance in series with the line, via two integral ferrite beads, and low inductance to ground via the bypass capacitor. Thus they provide increased attenuation with frequency over conventional decoupling capacitors
Note: See 'key characteristics' table for details of effective frequency ranges
Applications include:
High frequency noise suppression for d.c. power linesNoise suppression in digital high impedance circuits
Noise suppression in high speed digital signals (clocks etc.)
Noise suppression in video IF signals
| Key Characteristics | ||
| 16V Series | ||
| Capacitance (pF) | Effective Frequency Ranges (MHz) : | Manu. Part No. |
| 22000 | 3-1000 | DSS6NF31C223Q55B |
| 50V Series | ||
| 22000 | 0.3-1000 | DSS9NC51H223Q55B |
| 100V Series | ||
| 47 | 500-2000 | DSS6NC52A470Q55B |
| 100 | 300-2000 | DSS6NC52A101Q55B |
| 220 | - | DSS6NC52A221Q55B |
| 270 | 90-1000 | DSS6NC52A271Q55B |
| 470 | 70-1000 | DSS6NC52A471Q55B |
| 1000 | 30-1000 | DSS6NC52A102Q55B |
| 2200 | 10-1000 | DSS6NE52A222Q55B |
| 10000 | 7-1000 | DSS6NZ82A103Q55B |
| 250V Series | ||
| 100 | 300-2000 | DSS9HB32E101Q55B |
| 270 | 90-1000 | DSS9HB32E271Q55B |
| 2200 | 10-1000 | DSS9HB32E222Q55B |
| Operating Temp. Range | -25°C to +85°C | |
Signal/Line/Noise and Feedthrough - PCB Mount
Specifications
| Series | DSN6 | |
| Maximum Current Rating | 6A | |
| Maximum Voltage Rating | 100 V dc | |
| Mounting Type | Through Hole | |
| Termination Style | Radial | |
| Dimensions | 8 x 2.54 x 7mm | |
| Depth | 2.54mm | |
| Height | 7mm | |
| Length | 8mm | |
| Maximum Operating Temperature | +85°C | |
| Minimum Operating Temperature | -25°C |
