Microchip PIC16F1823-I/ST, 8bit PIC Microcontroller, 32MHz, 256 B, 2K x 14 words Flash, 14-Pin TSSOP
- BMUK Part # :-703-7810P
- BrandMicrochip
- Mfr. Part No.PIC16F1823-I/ST
-
- You will get a pack of 5 Microcontrollers
Product Details
PIC16F1823 8-Bit Flash Microcontrollers
The PIC16F range of Microcontrollers from Microchip are 8-bit MCUs that incorporate Microchip’s PIC® architecture into a variety of pin and package options, from space efficient 14-pin devices to feature-rich 64-pin devices. Devices with Baseline, Mid-Range or Enhanced Mid-Range architecture are available with numerous different peripheral combinations, giving designers flexibility and choice for their applications.
The PIC16F1823 family of microcontrollers is based upon Microchip’s Enhanced Mid-Range core with a 16 level deep hardware stack and 49 instructions. These MCUs provide up to 8 MIPS, 3.5 Kbytes program memory, 128 bytes RAM and 256 bytes EEPROM. On board is a configurable oscillator factory calibrated to ±1% accuracy.
Microcontroller Features
32 MHz Max. CPU Speed49 Instructions
16 Level Hardware Stack
32 MHz Internal Oscillator – Selectable Frequency Range 32 MHz to 31 kHz
12 I/O Pins
XLP Technology
Power-On Reset (POR)
Power-Up Timer (PWRT)
Oscillator Start-Up Timer (OST)
Brown-Out Reset (BOR)
Watchdog Timer (WDT)
In-Circuit Serial Programming (ICSP)
In-Circuit Debug (ICD)
Enhanced Low-Voltage Programming (LVP)
Peripherals
8 Channel 10-bit Analogue to Digital Converter (ADC)8 Channel Capacitive Sensing (mTouchTM) Module
Enhanced Capture/Compare/PWM (ECCP) Module
Two Comparators
Voltage Reference Module
Two 8-bit Timers
One 16-bit Timer
Data Signal Modulator Module
SR Latch
PIC16 Microcontrollers
Specifications
| Family Name | PIC16F | |
| Package Type | TSSOP | |
| Mounting Type | Surface Mount | |
| Pin Count | 14 | |
| Device Core | PIC | |
| Data Bus Width | 8bit | |
| Program Memory Size | 2K x 14 words, 256 B | |
| Maximum Frequency | 32MHz | |
| RAM Size | 128 B | |
| Number of PWM Units | 1 | |
| ADC Channels | 8 | |
| Number of SPI Channels | 1 | |
| Typical Operating Supply Voltage | 1.8 → 5.5 V | |
| Instruction Set Architecture | RISC | |
| ADC Resolution | 10bit | |
| Timer Resolution | 8 bit, 16 bit | |
| Timers | 1 x 16 bit, 2 x 8 bit | |
| Dimensions | 5.1 x 4.5 x 1.05mm | |
| Length | 5.1mm | |
| Pulse Width Modulation | 1(ECCP Full Bridge) | |
| Program Memory Type | Flash | |
| Number of I2C Channels | 1 | |
| Minimum Operating Temperature | -40 °C | |
| Height | 1.05mm | |
| Maximum Operating Temperature | +85 °C | |
| Number of Timers | 3 | |
| Number of ADC Units | 1 | |
| Width | 4.5mm | |
| ADCs | 8 x 10 bit | |
| Number of USART Channels | 1 |
