5 x Lite-On SBL1040 Diode, 40V 10A, 2-Pin TO-220AC - Lite-On

roll over the image to zoom in

£0.00
£7.99
RS 701-0360
Earn0
reward points

In stock: 3

Sorry! We're out of stock

Add To Your Wishlist
    Unit Quantity:
    5
    Unit Type:
    Unit
    Location:
    ES-6A


    Lite-On

    Lite-On SBL1040 Diode, 40V 10A, 2-Pin TO-220AC

    • BMUK Part # :-701-0360
    • BrandLite-On
    • Mfr Part No.SBL1040
    •  Lite-On
    •
    • You will get a pack of 5 Diodes
    Lite-On SBL1040 Diode, 40V 10A, 2-Pin TO-220AC








    Product Details

    Schottky Barrier Diodes, Lite-On







    Diodes and Rectifiers, Lite-On

    Specifications

    Diode Configuration
    Single
    Maximum Operating Temperature
    +125 °C
    Number of Elements per Chip
    1
    Length
    10.67mm
    Brand
    Lite-On
    Package Type
    TO-220AC
    Maximum Continuous Forward Current
    10A
    Mounting Type
    Through Hole
    Minimum Operating Temperature
    -55 °C
    Width
    4.83mm
    Height
    16.14mm
    Maximum Forward Voltage Drop
    600mV
    Pin Count
    2
    Dimensions
    10.67 x 4.83 x 16.14mm
    Peak Non-Repetitive Forward Surge Current
    250A
    Peak Reverse Current
    50mA
    Diode Type
    Schottky
    Peak Reverse Repetitive Voltage
    40V
