5 x KEMET 100nF Polyester Capacitor R82DC3100DQ50J PET 40V ac, 63V dc ±5% - Kemet
roll over the image to zoom in
£0.00
£5.49
RS 312-1469
Unit Quantity:
5
Unit Type:
Unit
Kemet
KEMET 100nF Polyester Capacitor PET 40 V ac, 63 V dc ±5% R82 Series Through Hole
- BMUK Part # :-312-1469
- BrandKEMET
- Mfr. Part No.R82DC3100DQ50J
-
- You will get a pack of 5 Capacitors
Product Details
KEMET Miniature R82 Series
KEMET R82 series are metallised polyester film with radial leads of tinned wire. The R82 series radial leads are electrically welded to the contact metal layer on the ends of the capacitor winding. The capacitors are encapsulated in a self-extinguishing solvent resistant plastic case with thermosetting resin material. Typical applications for the R82 series include blocking, coupling, decoupling, timing and oscillator circuits.
Features
Wide voltage range 50 V dc to 400 V dcRoHS compliance and lead-free terminations
Self-healing
Capacitance range 0.001 μF – 4.7 μF
Lead Spacing 5 mm
Capacitance tolerance ±5%, ±10%, ±20%
Climatic category 55/105/56
Operating temperature range of -55˚C to +105˚C
Tape and reel packaging in accordance with IEC 60286–2
Automotive (AEC–Q200) grades available
Applications
Typical applications include blocking, coupling, decoupling, timingand oscillator circuits.
Metallised 105°C
Specifications
| Capacitance | 100 nF | |
| Voltage | 40 V ac, 63 V dc | |
| Mounting Type | Through Hole | |
| Lead Pitch | 5mm | |
| Series | R82 | |
| Tolerance | ±5% | |
| Dielectric | PET | |
| Length | 7.2mm | |
| Depth | 2.5mm | |
| Height | 6.5mm | |
| Dimensions | 2.5 x 6.5 x 7.2mm | |
| Minimum Operating Temperature | -55°C | |
| Maximum Operating Temperature | +105°C | |
| Application | Blocking, Coupling, Decoupling, Oscillator circuits, Timing | |
| Tolerance Minus | -5% | |
| Lead Diameter | 0.5mm | |
| Board Level Components | Y | |
| Tolerance Plus | +5% | |
| CAD Drawing | 3D CAD Model | |
| Dielectric Material Family | Polyester Film |
