5 x Infineon IRF7422D2PBF P-channel MOSFET Transistor, 4.3A, 20V, 8-Pin SOIC - Infineon
roll over the image to zoom in
£0.00
£5.99
RS 543-2452
Unit Quantity:
5
Unit Type:
Unit
Location:
TS BRA-10D
Infineon
Infineon IRF7422D2PBF P-channel MOSFET Transistor, 4.3 A, 20 V, 8-Pin SOIC
- BMUK Part # :-543-2452
- BrandInfineon
- Mfr Part No.IRF7422D2PBF
-
- You will get a pack of 5 Transistors
Product Details
FETKY™ IRF73xx / IRF74xx / IRF75xx / IRF78xx, Infineon
MOSFET Transistors, Infineon
Specifications
Maximum Operating Temperature
+150 °C
Number of Elements per Chip
1
Length
5mm
Transistor Configuration
Single
Typical Turn-On Delay Time
8.4 ns
Brand
Infineon
Typical Turn-Off Delay Time
51 ns
Maximum Continuous Drain Current
4.3 A
Package Type
SOIC
Maximum Power Dissipation
2 W
Mounting Type
Surface Mount
Minimum Operating Temperature
-55 °C
Width
4mm
Maximum Gate Threshold Voltage
0.7V
Minimum Gate Threshold Voltage
0.7V
Height
1.5mm
Maximum Drain Source Resistance
90 mΩ
Maximum Drain Source Voltage
20 V
Pin Count
8
Dimensions
5 x 4 x 1.5mm
Category
Power MOSFET
Typical Gate Charge @ Vgs
15 nC @ 4.5 V
Channel Mode
Enhancement
Typical Input Capacitance @ Vds
610 pF @ 15 V
Channel Type
P
Maximum Gate Source Voltage
-12 V, +12 V
