5 x Infineon IPS65R400CEAKMA1, N-Channel MOSFET, 15.1A, 700V, 3-Pin IPAK - Infineon
roll over the image to zoom in
£0.00
£5.99
RS 130-0928 + RS 168-5940
Unit Quantity:
10
Unit Type:
Unit
Location:
ES 10L + TS BRA 5F
Infineon
N-Channel MOSFET, 15.1 A, 700 V, 3-Pin IPAK Infineon IPS65R400CEAKMA1
- BMUK Stock No.130-0928
- Brand
- Mfr Part No.IPS65R400CEAKMA1
- You will get FIVE MOSFET's
Product Details
Infineon CoolMOS™ CE Power MOSFET
MOSFET Transistors, Infineon
Specifications
Maximum Operating Temperature
+150 °C
Number of Elements per Chip
1
Length
6.73mm
Brand
Infineon
Maximum Continuous Drain Current
15.1 A
Package Type
IPAK (TO-251)
Maximum Power Dissipation
118 W
Series
CoolMOS CE
Mounting Type
Through Hole
Minimum Operating Temperature
-55 °C
Width
2.4mm
Maximum Gate Threshold Voltage
3.5V
Minimum Gate Threshold Voltage
2.5V
Height
6.22mm
Maximum Drain Source Resistance
400 mΩ
Maximum Drain Source Voltage
700 V
Pin Count
3
Typical Gate Charge @ Vgs
39 nC @ 10 V
Channel Mode
Enhancement
Channel Type
N
Maximum Gate Source Voltage
-30 V, +30 V
Forward Diode Voltage
0.9V
