5 x Infineon IPP80P04P4L-08 P-channel MOSFET Transistor, 80A, 40V, 3-Pin TO-220 - Infineon
roll over the image to zoom in
£0.00
£8.99
RS 857-7022
Infineon
Infineon IPP80P04P4L-08 P-channel MOSFET Transistor, 80A, 40V
- You will get a pack of 5 MOSFET's,
- BMUK Part # :-857-7022
- BrandInfineon
- Mfr. Part No.IPP80P04P4L-08
-
Product Details
Infineon OptiMOS™P P-Channel Power MOSFETs
The InfineonOptiMOS™ P-Channel power MOSFETs are designed to give enhanced features meeting quality performances. Features include ultra-low switching loss, on-state resistance, Avalanche ratings as well as being AEC qualified for automotive solutions. Applications include dc-dc, motor control, automotive and eMobility.
Enhancement mode
Avalanche rated
Low switching and conduction power losses
Pb-free lead plating; RoHS compliant
Standard packages
OptiMOS™ P-Channel Series: Temperature range from -55°C to +175°C
MOSFET Transistors, Infineon
Infineon’s large and comprehensive portfolio of MOSFET devices includes the OptiMOS™ and CoolMOS™ families. These products deliver best-in-class performance from the latest generation of state-of-the-art power MOSFETs
Specifications
| Channel Type | P | |
| Maximum Continuous Drain Current | 80 A | |
| Maximum Drain Source Voltage | 40 V | |
| Maximum Drain Source Resistance | 0.0133 Ω | |
| Maximum Gate Threshold Voltage | 2.2V | |
| Minimum Gate Threshold Voltage | 1.2V | |
| Maximum Gate Source Voltage | ±16 V | |
| Package Type | TO-220 | |
| Mounting Type | Through Hole | |
| Pin Count | 3 | |
| Channel Mode | Enhancement | |
| Category | Power Transistor | |
| Maximum Power Dissipation | 75 W | |
| Configuration | Single | |
| Minimum Operating Temperature | -55 °C | |
| Number of Elements per Chip | 1 | |
| Height | 15.65mm | |
| Typical Input Capacitance @ Vds | 4177 pF @ -25 V | |
| Typical Turn-On Delay Time | 12 ns | |
| Typical Turn-Off Delay Time | 42 ns | |
| Dimensions | 10 x 4.4 x 15.65mm | |
| Length | 10mm | |
| Maximum Operating Temperature | +175 °C | |
| Typical Gate Charge @ Vgs | 71 nC @ -10 V | |
| Width | 4.4mm |
