    Infineon BSC050N03MSGATMA1 N-channel MOSFET, 80 A, 30 V OptiMOS 3, 8-Pin TDSON



    • BMUK Part # :- 754-5263
    • BrandInfineon
    • Mfr Part No.BSC050N03MS G
    •  Infineon
    •
    • You will get a pack of 5 Transistors














    Product Details

    Infineon OptiMOS™3 Power MOSFETs, up to 40V

    OptiMOS™ products are available in high performance packages to tackle the most challenging applications giving full flexibility in limited spaces. These Infineon products are designed to meet and exceed the energy efficiency and power density requirements of the sharpened next generation voltage regulation standards in computing applications.






    MOSFET Transistors, Infineon

    Specifications


    Maximum Operating Temperature
    +150 °C
    Number of Elements per Chip
    1
    Length
    5.35mm
    Transistor Configuration
    Single
    Typical Turn-On Delay Time
    14 ns
    Brand
    Infineon
    Typical Turn-Off Delay Time
    16 ns
    Maximum Continuous Drain Current
    80 A
    Package Type
    TDSON
    Maximum Power Dissipation
    50 W
    Series
    OptiMOS 3
    Mounting Type
    Surface Mount
    Minimum Operating Temperature
    -55 °C
    Width
    6.1mm
    Maximum Gate Threshold Voltage
    2V
    Minimum Gate Threshold Voltage
    1V
    Height
    1.1mm
    Maximum Drain Source Resistance
    6.3 mΩ
    Maximum Drain Source Voltage
    30 V
    Pin Count
    8
    Dimensions
    5.35 x 6.1 x 1.1mm
    Typical Gate Charge @ Vgs
    34 nC @ 10 V
    Transistor Material
    Si
    Channel Mode
    Enhancement
    Typical Input Capacitance @ Vds
    2700 pF @ 15 V
    Channel Type
    N
    Maximum Gate Source Voltage
    -20 V, +20 V
