5 x Fairchild Semiconductor Single Linear Voltage Regulator LM78L05ACZX 100mA 5V - Fairchild Semiconductor
roll over the image to zoom in
£0.00
£7.49
RS 903-4327P
Unit Quantity:
5
Unit Type:
Unit
Location:
TS 41F
Fairchild Semiconductor
Fairchild Semiconductor LM78Lxx LM78L05ACZ, Single Linear Voltage Regulator, 100mA 5 V, ±5%, 3-Pin TO-92
- BMUK Part # :-903-4327P
- BrandFairchild Semiconductor
- Mfr. Part No.LM78L05ACZX
- You will get a pack of 5 Voltage Regulators
Product Details
Linear Voltage Regulators, Fairchild Semiconductor
High reliability voltage regulators
Fixed output voltages
Low dynamic output impedance
Fast turn-on response
Wide operating temperature range
Protection with thermal shut-down
Linear Voltage Regulators, Fairchild Semiconductor
Specifications
| Output Voltage | 5 V | |
| Maximum Output Current | 100mA | |
| Package Type | TO-92 | |
| Output Type | Fixed | |
| Mounting Type | Through Hole | |
| Maximum Input Voltage | 35 V | |
| Pin Count | 3 | |
| Minimum Operating Temperature | -40 °C | |
| Maximum Operating Temperature | +125 °C | |
| Number of Outputs | 1 | |
| Polarity | Positive | |
| Dropout Voltage Measurement Current | 40 mA | |
| Accuracy | ±5% | |
| Quiescent Current | 5.5mA | |
| Dimensions | 5.2 x 4.19 x 5.33mm | |
| Load Regulation | 60 mV | |
| Typical Dropout Voltage @ Current | 1.7 V @ 40 mA | |
| Width | 4.19mm | |
| Length | 5.2mm | |
| Line Regulation | 150 mV | |
| Height | 5.33mm | |
| Series | LM78Lxx |
