5 x Fairchild Semiconductor LM78L12ACZ, LDO Voltage Regulator, 100mA, 12V ±5% - Fairchild Semiconductor
roll over the image to zoom in
£0.00
£6.99
RS 761-3656
Unit Quantity:
5
Unit Type:
Unit
Location:
TS 30R
Fairchild Semiconductor
Fairchild Semiconductor LM78L12ACZ, LDO Voltage Regulator, 100mA, 12 V ±5%, 3-Pin TO-92
- BMUK Part # :-761-3656
- BrandFairchild Semiconductor
- Mfr. Part No.LM78L12ACZ
- You will get a pack of 5 Voltage Regulators
Product Details
Linear Voltage Regulators, Fairchild Semiconductor
High-reliability voltage regulators
Fixed output voltages
Low dynamic output impedance
Fast turn-on response
Wide operating temperature range
Protection with thermal shut-down
Linear Voltage Regulators, Fairchild Semiconductor
Specifications
| Output Voltage | 12 V | |
| Output Type | Fixed | |
| Package Type | TO-92 | |
| Maximum Output Current | 100mA | |
| Mounting Type | Through Hole | |
| Maximum Input Voltage | 35 V | |
| Pin Count | 3 | |
| Number of Outputs | 1 | |
| Quiescent Current | 5.5mA | |
| Accuracy | ±5% | |
| Minimum Operating Temperature | 0 °C | |
| Maximum Operating Temperature | +150 °C | |
| Height | 5.33mm | |
| Length | 5.2mm | |
| Load Regulation | 60 mV | |
| Dimensions | 5.2 x 4.19 x 5.33mm | |
| Width | 4.19mm | |
| Line Regulation | 150 mV |
