5 x Cooper Bussmann FP3-150-R, Wire-wound SMD Inductor 15 uH ±15% 2.5A Idc - Cooper Bussmann
roll over the image to zoom in
£0.00
£4.99
RS 770-0451
Unit Quantity:
5
Unit Type:
Unit
Location:
APR SHELF BOX 5
Cooper Bussmann
Cooper Bussmann FP3-150-R Flat-Pac 3 Series Wire-wound SMD Inductor with a Composite Iron Powder Core, 15 μH ±15% 2.5A Idc
- BMUK Part # :-770-0451
- BrandCooper Bussmann
- Mfr. Part No.FP3-150-R
- You will get a pack of 5 Inductors
Product Details
Low Profile, High Current Inductors - FLAT-PAC™ 3 Series
FLAT-PAC™ 3 Series low profile high current inductors with a maximum total operating temperature of 155°C. The FLAT-PAC™ 3 series inductors have a high resistance to aging by virtue of their construction utilising a high temperature powdered iron material with a non-organic binder. Applications for FLAT-PAC™3 series include: computers and portable power devices; Energy storage applications; DC-DC converters; Input - Output filter applications
Cooper Bussmann Non Standard SMT Inductors (Chokes)
Specifications
| Inductance | 15 μH | |
| Maximum DC Current | 2.5A | |
| Package/Case | FP3 | |
| Length | 7.25mm | |
| Depth | 6.7mm | |
| Height | 3mm | |
| Dimensions | 7.25 x 6.7 x 3mm | |
| Tolerance | ±15% | |
| Maximum DC Resistance | 127mΩ | |
| Series | Flat-Pac 3 | |
| Core Material | Composite Iron Powder | |
| Maximum Self Resonant Frequency | 2MHz | |
| Minimum Operating Temperature | -40°C | |
| Moulded | Yes | |
| Maximum Operating Temperature | +155°C |
