5 x Bourns CRM Series Thick Film High Power Surface Mount Resistor, 1kΩ ±1% 2W - Bourns
roll over the image to zoom in
£0.00
£5.99
RS 720-3212P
Unit Quantity:
5
Unit Type:
Unit
Resistance Rating:
1K
Tolerance Rating:
1%
Location:
TS-ES 8I
Bourns
Bourns CRM Series Thick Film High Power Surface Mount Resistor 2512 Case 1kΩ ±1% 2W 100ppm/°C
- BMUK Part # :-720-3212P
- BrandBourns
- Mfr. Part No.CRM2512-FX-1001ELF
- Location :-TS-ES 8I
- You will get a pack of 5 Resistors
Product Details
CRM Series 2512 Format - Pulse Resistant
Bourns CRM2512 Series thickfilm power resistors with a rating of 2watts in a standard 2512 chip format. Having a very wide resistance range makes the CRM2512 Series suitable for different applications in power supply circuits including current sensing and inrush current limiting.
Current Sense - Surface Mount
Bulk metal chip resistors
Low thermal e.m.f.
Non-inductive
Marked with 3-digit resistance code
Mini reels are ideal for small batch production, development and R&D department
Suitable for automatic assembly on pick and place machinery
Specifications
| Resistance | 1 kΩ | |
| Package/Case | 2512 | |
| Tolerance | ±1% | |
| Power Rating | 2W | |
| Temperature Coefficient | 100ppm/°C | |
| Technology | Thick Film | |
| Dimensions | 6.3 x 0.6mm | |
| Length | 6.3mm | |
| Depth | 3.1mm | |
| Height | 0.6mm | |
| Series | CRM | |
| Minimum Operating Temperature | -55°C | |
| Maximum Operating Temperature | +155°C | |
| Termination Style | Solder Pad | |
| Case Style | Moulded | |
| Minimum Temperature Coefficient | -200ppm/°C | |
| Maximum Temperature Coefficient | +200ppm/°C |
