5 x 4700uF 10V Aluminium Electrolytic Capacitor, Axial 85°C, ±20% - RS
roll over the image to zoom in
£0.00
£7.99
RS 267-4596
Unit Quantity:
5
Unit Type:
Unit
RS
4700μF 10V Aluminium Electrolytic Capacitor, Axial 85°C, ±20%
You will get a bag of 5 Capacitors
- Axial Capacitor 30mm L x 16mm D, 85°C
- BrandRS
Product Details
AMA Series
Axial leaded electrolytic capacitors offering wide capacitance values and voltage ratings, small case sizes, high ripple current ratings and low leakage current
Life expectancy 1000 hours
RS, Professionally Approved Products, gives you professional quality parts across all product categories. Our range has been testified by engineers as giving comparable quality to that of the leading brands without paying a premium price.
| Technical specification | |
| Capacitance tolerance | 20 % |
| Operating Temperature (°C) | -40 to 85 |
| Leakage current (whichever is the greater) | 0.01CV or 3μA min. at 5 mins (up to 100Vdc) 0.01CV+100μA min. at 5 mins (over 100Vdc) |
Axial 85°C
Specifications
| Capacitance | 4700µF | |
| Construction | Axial | |
| Leakage Current | 0.01 CV or 3 μA@ 5 min | |
| Lifetime | 1000h | |
| Maximum Operating Temperature | +85°C | |
| Minimum Operating Temperature | -40°C | |
| Technology | Electrolytic | |
| Tolerance | ±20% | |
| Tolerance Minus | -20% | |
| Tolerance Plus | +20% | |
| Size (LxD) | 30mm x 16mm | |
| Voltage | 10 V |
