4x TE Connectivity Radial Ceramic 5W Power Resistor Range, Chose Value ±5% - TE Connectivity

roll over the image to zoom in

£0.00
£7.49
Earn0
reward points

In stock

Sorry! We're out of stock

Add To Your Wishlist
    Material:
    Ceramic
    Tolerance Rating:
    ±5 %
    Power Rating:
    5 W


    TE Connectivity

    TE Connectivity(MEGGITT) Radial Ceramic Power Resistor Range ±5% 5W ±300ppm/°C

    You Will Receive A Pack of 4 Resistors


    • BrandTE Connectivity/Meggitt

    • TE Connectivity


    Image Representative Of Range
    Product Details

    5W SQM5 Series

    TE Connectivity SQ series high power resistors featuring fine non-alkali ceramic cores embodied in ceramic cases and sealed with inorganic silica filler. This provides the SQ series with high insulation resistance, low surface temperature, excellent TCR and an entirely fireproof construction. The SQ series resistors are ideally suited to any application where efficient thermal performance is required.

    Flameproof
    Power rating of 5W at 70°C
    Resistor marked with value
    Overload Maximum 700V
    Working Voltage 350V
    Ideal for small batch production, development and R&D department

    Wirewound, Radial-4W/5W/7W

    Specifications



    Power Rating5W
    Tolerance±5%
    Case StyleCeramic
    Temperature Coefficient±300ppm/°C
    Termination StyleRadial
    Dimensions13 x 9 x 25mm
    Length13mm
    Depth9mm
    Height25mm
    Lead Pitch5mm
    Minimum Temperature Coefficient-300ppm/°C
    Minimum Operating Temperature-55°C
    Maximum Temperature Coefficient+300ppm/°C
    Maximum Operating Temperature+250°C

    Click to view the full DATA SHEET
