4x TE Connectivity Axial Ceramic 5W Power Resistor Range, Chose Value ±5% - TE Connectivity
roll over the image to zoom in
£0.00
£6.99
Material:
Ceramic
Tolerance Rating:
±5 %
Termination Style:
Axial
Power Rating:
5 W
TE Connectivity
TE Connectivity Axial Ceramic Power Resistor Range ±5% 5W ±300ppm/°C
You Will Receive A Pack Of 4 Resistors
- BrandTE Connectivity/Meggitt
Image Representative Of Range
Product Details
5W SQM5 Series
TE Connectivity SQ series high power resistors featuring fine non-alkali ceramic cores embodied in ceramic cases and sealed with inorganic silica filler. This provides the SQ series with high insulation resistance, low surface temperature, excellent TCR and an entirely fireproof construction. The SQ series resistors are ideally suited to any application where efficient thermal performance is required.
Flameproof
Power rating of 5W at 70°C
Resistor marked with value
Overload Maximum 700V
Working Voltage 350V
Ideal for small batch production, development and R&D department
Wirewound, Axial-4W/5W/7W
Specifications
| Power Rating | 5W | |
| Tolerance | ±5% | |
| Case Style | Ceramic | |
| Temperature Coefficient | ±300ppm/°C | |
| Termination Style | Axial | |
| Dimensions | 22 x 10 x 9 | |
| Length | 22mm | |
| Depth | 10mm | |
| Height | 9mm | |
| Minimum Temperature Coefficient | -300ppm/°C | |
| Minimum Operating Temperature | -55°C | |
| Maximum Temperature Coefficient | +300ppm/°C | |
| Maximum Operating Temperature | +250°C |
Click to view the full DATA SHEET
