45 x Vishay MBRB2060CT-E3 Dual SMT Diode, Common Cathode, 60V 20A, 3-Pin D2PAK - Vishay
roll over the image to zoom in
£0.00
£46.99
RS 640-4385
Unit Quantity:
45
Unit Type:
Unit
Location:
BRA5H
Vishay
Vishay MBRB2060CT-E3 Dual SMT Diode, Common Cathode, 60V 20A, 3-Pin D2PAK
- BMUK Part # :- 640-4385
- BrandVishay
- Mfr. Part No.MBRB2060CT-E3
-
- You will get a tube of 45 Diodes
Product Details
High-Performance Schottky Rectifiers 16A to 25A, Vishay Semiconductor
Schottky Rectifiers are semiconductor diodes that exhibit very low forward voltage drop with a very fast switching action. The reverse recovery times of Schottky diodes are extremely quick. Schottky diodes are suitable for applications requiring fast switching and low power loss.
Schottky Rectifiers, Vishay Semiconductor
Specifications
| Diode Configuration | Common Cathode | |
| Maximum Continuous Forward Current | 20A | |
| Number of Elements per Chip | 2 | |
| Peak Reverse Repetitive Voltage | 60V | |
| Mounting Type | Surface Mount | |
| Package Type | TO-263AB | |
| Diode Type | Schottky | |
| Pin Count | 3 | |
| Length | 10.67mm | |
| Width | 9.65mm | |
| Height | 4.83mm | |
| Dimensions | 4.83 x 10.67 x 9.65mm | |
| Maximum Operating Temperature | +150 °C | |
| Peak Reverse Current | 150µA | |
| Peak Non-Repetitive Forward Surge Current | 150A | |
| Minimum Operating Temperature | -65 °C |
