4 x Nippon Chemi-Con LXZ Aluminium Electrolytic Capacitor 1500uF 16V dc 10mm - Nippon Chemi-Con
roll over the image to zoom in
£0.00
£7.99
RS 756-LXZ
Type:
Electrolytic Capacitor
Material:
Aluminium
Unit Quantity:
4
Unit Type:
Unit
Maximum Operating Voltage:
16 V
Location:
TS 1A
Nippon Chemi-Con
Nippon Chemi-Con Aluminium Electrolytic Capacitor 1500μF 16V dc 10mm Through Hole K30 series LXZ lifetime 7000h
- BMUK Part # :-756-LXZ
- BrandNippon Chemi-Con
- Mfr. Part No.ELXZ160ELL152MK30S
- Location :-TS 1A
-
- You will get a pack of 4 Capacitors
Product Details
LXZ Series
Radial aluminium electrolytic capacitor with very low impedance at high frequency and good endurance. Solvent resistant (see datasheet for guidelines)
Radial 105°C
Specifications
| Capacitance | 1500 µF | |
| Technology | Electrolytic | |
| Voltage | 16 V dc | |
| Dimensions | 10.0 x 30mm | |
| Height | 30mm | |
| Diameter | 10.0mm | |
| Minimum Operating Temperature | -55°C | |
| Maximum Operating Temperature | +105°C | |
| Lead Pitch | 5mm | |
| Construction | Radial | |
| Series | LXZ | |
| Leakage Current | 0.01 CV μA, 3 μA@ 20°C (After 2 min) | |
| Tolerance Plus | +20% | |
| Equivalent Series Resistance | 50mΩ | |
| Tolerance | ±20% | |
| Tolerance Minus | -20% | |
| Package/Case | K30 | |
| Ripple Current | 2310mArms | |
| Lead Diameter | 0.6mm | |
| Lifetime | 7000h |
For a Specification PDF Please CLICK HERE
