281 x Panasonic DSA7503S0L PNP Bipolar Transistor, 1A, 20V, 3-Pin MiniP3 F2 B - Panasonic
roll over the image to zoom in
£0.00
£103.99
RS 711-5727
Unit Quantity:
281
Unit Type:
Unit
Location:
APR BOX E
Panasonic
Panasonic DSA7503S0L PNP Bipolar Transistor, 1 A, 20 V, 3-Pin MiniP3 F2 B
- BMUK Part # :-711-5727
- BrandPanasonic
- Mfr Part No.DSA7503S0L
-
- You will get approx 281 Transistors on a Reel
Image representative of range only
Product Details
General Purpose PNP Transistors, Panasonic
Bipolar Transistors, Panasonic
Specifications
Maximum Collector Emitter Saturation Voltage
-0.5 V
Maximum Operating Temperature
+150 °C
Maximum Operating Frequency
200 MHz
Number of Elements per Chip
1
Maximum Base Emitter Saturation Voltage
-1.2 V
Length
4.5mm
Maximum Collector Base Voltage
-20 V
Brand
Panasonic
Maximum Collector Emitter Voltage
20 V
Package Type
MiniP3 F2 B
Maximum Power Dissipation
1 W
Mounting Type
Surface Mount
Width
2.5mm
Maximum DC Collector Current
1 A
Transistor Type
PNP
Height
1.5mm
Pin Count
3
Maximum Emitter Base Voltage
-5 V
Dimensions
4.5 x 2.5 x 1.5mm
Minimum DC Current Gain
180
