25x UA78L05ACDR Texas Instruments 1 Linear Voltage Regulator 100mA 5V 8-Pin SOIC - Texas Instruments

roll over the image to zoom in

£0.00
£7.95
RS 527-974 / TSB-40D-RB5
Earn0
reward points

In stock: 0

Sorry! We're out of stock

Add To Your Wishlist
    Unit Quantity:
    25
    Unit Type:
    Unit
    Location:
    TSB-40D-RB5


    Texas Instruments

    UA78L05ACDR Texas Instruments 1 Linear Voltage Regulator 100mA 5V 8-Pin SOIC

    You will get FIVE HUNDRED resistors

    Description:
    The Texas Instruments μA78 families are linear voltage regulators that cover a range of fixed output voltages from 2.6 V to 15 V.The three terminal positive voltage regulators offer thermal overload shutdown and internal current limiting. There is no need for external components although it is possible to adjust the voltage and current with external devices. The TI positive linear regulator IC produces an output current of 1.5A for the μA78 series, 0.1A for the μA78L version and the μA78M offers 0.5A current output. It is used in a wide variety of applications including on-card regulation which eliminates problems that occur with single point regulation also suitable in telecommunications, computing and portable device applications.

    Output Current: 1.5 A (μA78xx); 0.1 A (μA78Lxx) and 0.5 A (μA78Mxx)
    Internal Thermal-Overload Protection, Internal Short-Circuit Current Limiting
    Output Transistor Safe-Area Compensation
    High Power-Dissipation

    Specifications:
    • Type: Linear Voltage Regulator
    • Brand: Texas Instruments
    • Model: UA78L05ACDR
    • Output Voltage: 5V
    • Output Current: 100mA
    • Package Type: 8-Pin SOIC
    • Quantity: 25x
    • Part Number (MPN): UA78L05ACDR
