25 x Panasonic Aluminium Electrolytic Capacitor 120uF 25V dc 6.3mm, 1000h 105°C - Panasonic
roll over the image to zoom in
£0.00
£7.99
RS 315-0546
Unit Quantity:
25
Unit Type:
Unit
Location:
TS-LB 6C
Panasonic
Panasonic Aluminium Electrolytic Capacitor 120μF 25 V dc 6.3mm Through Hole FC Radial Series Lifetime 1000h 105°C
- BMUK Part # :-315-0546
- BrandPanasonic
- Mfr. Part No.EEUFC1E121
- You will get a pack of 25 Capacitors
Product Details
FC Series 120μF - 270μF
Panasonic FC Series Type A electrolytic capacitors offer a high endurance, low impedance solution. These aluminium capacitors feature endurance between 1000 and 5000 hours.
AEC-Q200 qualified
Radial lead type
Low ESR
Compact size
High reliability
Low impedance
High ripple current
Applications
Panasonic FC Type A electrolytic capacitors are AEC-Q200 qualified and suitable for automotive applications. High reliability also makes these electrolytic capacitors ideal for application in industrial instruments.
Specifications
| Capacitance | 120 µF | |
| Technology | Electrolytic | |
| Voltage | 25 V dc | |
| Mounting Type | Through Hole | |
| Dimensions | 6.3 (Dia.) x 15mm | |
| Height | 15mm | |
| Diameter | 6.3mm | |
| Minimum Operating Temperature | -55°C | |
| Maximum Operating Temperature | 105°C | |
| Lead Pitch | 2.5mm | |
| Construction | Radial | |
| Series | FC Radial | |
| Leakage Current | 3 μA | |
| Lead Diameter | 0.5mm | |
| Ripple Current | 400mA | |
| Tolerance Plus | +20% | |
| Lifetime | 1000h | |
| Equivalent Series Resistance | 250mΩ | |
| Tolerance | ±20% | |
| Tolerance Minus | -20% | |
| Terminal Type | Through Hole |
