2116 x Panasonic Zener Diode DZ2S18000L, 18V 5% 150mW SMT 2-Pin SSMini2 F5 B - Panasonic
roll over the image to zoom in
£0.00
£172.99
RS 710-6209
Unit Quantity:
2116
Unit Type:
Unit
Location:
APR BOX F
Panasonic
Panasonic Zener Diode, 18V 5% 150 mW SMT 2-Pin SSMini2 F5 B
- BMUK Part # : 710-6209
- BrandPanasonic
- Mfr. Part No.DZ2S18000L
-
- You will get 2116 Diodes on a Reel
Product Details
Zener Diodes 150mW, DZ2S Series, Panasonic
Zener Diodes, Panasonic
Specifications
| Diode Configuration | Single | |
| Nominal Zener Voltage | 18V | |
| Number of Elements per Chip | 1 | |
| Mounting Type | Surface Mount | |
| Maximum Power Dissipation | 150 mW | |
| Package Type | SSMini2 F5 B | |
| Zener Type | General Purpose | |
| Zener Voltage Tolerance | 5% | |
| Pin Count | 2 | |
| Test Current | 5mA | |
| Maximum Zener Impedance | 80Ω | |
| Maximum Reverse Leakage Current | 50nA | |
| Length | 1.2mm | |
| Dimensions | 1.2 x 0.8 x 0.6mm | |
| Height | 0.6mm | |
| Maximum Operating Temperature | +150 °C | |
| Typical Voltage Temperature Coefficient | 17.2mV/°C | |
| Width | 0.8mm |
