20 x Vishay Aluminium Electrolytic Capacitor MAL203854101E3, 100uF 10V dc - Vishay
roll over the image to zoom in
£0.00
£5.49
RS 684-1872
Unit Quantity:
1
Unit Type:
Unit
Location:
TS 1I
Vishay
Vishay Aluminium Electrolytic Capacitor 100μF 10 V dc 5mm Through Hole series 038 RSU lifetime 2500h
- BMUK Part # :-684-1872
- BrandVishay
- Mfr. Part No.MAL203854101E3
- You will get a pack of 20 Capacitors
Product Details
038 RSU series radial
Ultra miniature radial electrolitic capacitor
Insulated with blue vinyl sleeve
General purpose use, industrial, automotive, consumer, and audio-video
| Capacitance Tolerance (%) | 20 |
| Operating Temperature (°C) | -40 to +85 |
| Life expectancy at 85°C | 2500Hrs ≤ 8mm diam 3500 Hrs ≥ 10mm diam |
Radial 85°C
Specifications
| Capacitance | 100 µF | |
| Technology | Electrolytic | |
| Voltage | 10 V dc | |
| Dimensions | 5 (Dia.) x 11mm | |
| Height | 11mm | |
| Diameter | 5mm | |
| Minimum Operating Temperature | -40°C | |
| Maximum Operating Temperature | +85°C | |
| Lead Pitch | 2mm | |
| Construction | Radial | |
| Series | 038 RSU | |
| Tolerance | ±20% | |
| Tolerance Minus | -20% | |
| Ripple Current | 145mA | |
| Lead Diameter | 0.5mm | |
| Leakage Current | 10 μA | |
| Lifetime | 2500h | |
| Terminal Type | Through Hole | |
| Tolerance Plus | +20% |
