20 x NXP PMZ250UN 315 N-channel MOSFET Transistor, 2.28A, 20V, SM 3-Pin SOT-883 - NXP
roll over the image to zoom in
£0.00
£5.40
RS 725-8445
NXP
NXP PMZ250UN,315 N-channel MOSFET Transistor, 2.28 A, 20 V, 3-Pin SOT-883
You will get 20 Transistors on SM Tape, Multi Buys will come on one legnth of tape
Product Details
N-Channel MOSFET, 1A to 9A, NXP Semiconductors
MOSFET Transistors, NXP Semiconductors
Specifications
| Category | Power MOSFET | |
| Channel Mode | Enhancement | |
| Channel Type | N | |
| Configuration | Single | |
| Dimensions | 1.02 x 0.62 x 0.47mm | |
| Height | 0.47mm | |
| Length | 1.02mm | |
| Maximum Continuous Drain Current | 2.28 A | |
| Maximum Drain Source Resistance | 0.3 Ω | |
| Maximum Drain Source Voltage | 20 V | |
| Maximum Gate Source Voltage | ±8 V | |
| Maximum Operating Temperature | +150 °C | |
| Maximum Power Dissipation | 2.5 W | |
| Minimum Operating Temperature | -55 °C | |
| Mounting Type | Surface Mount | |
| Number of Elements per Chip | 1 | |
| Package Type | SOT-883 | |
| Pin Count | 3 | |
| Typical Gate Charge @ Vgs | 0.89 nC V @ 4.5 | |
| Typical Input Capacitance @ Vds | 45 pF V @ 20 | |
| Typical Turn-Off Delay Time | 18.5 ns | |
| Typical Turn-On Delay Time | 4.5 ns | |
| Width | 0.62mm |
Specification PDF Please CLICK HERE
