20 of Axial Carbon Film Resistors of your chosen Ω Value ±5% ¼ Watt Electronics - RS Pro

roll over the image to zoom in


£0.00
£4.49

Earn0
reward points


In stock

Sorry! We're out of stock


    Unit Quantity:
    20
    Unit Type:
    Unit


    RS Pro

    Axial Carbon Film Resistors of your chosen value ±5% ¼W


    You will get 20 resistors on tape

    We now have extra values of 1.5Ω, 7.5Ω and 4.3KΩ that are not on the selection list, let us know if you require any of these and we will add them to your order and send an updated invoice including the extra items,

    RS
    RS RS Series Axial Carbon Resistor 100Ω ±5% 0.25W -500 → +350ppm/°C
    Product Details

    Carbon Film Resistors 0.25W

    The RS series of carbon film axial leaded resistors offer excellent long-term stability, and feature standard solder-plated copper leads. Applications include automotive, telecommunication, and medical equipment.

    Features and Benefits

    Available in resistances from 1 Ohm to 9.1 mOhm
    0.25W power rating
    5% tolerance
    Resistor body 2.3 mm in diameter, 6.3 mm in length
    Carbon film construction
    Long-term stability
    Solder plated copper leads



    Power at 70°C0.25W
    Resistance Tolerance±5%
    Temperature Coefficient
    <100KΩ+350ppm to -500ppm
    100KΩ to 1MΩ0ppm to -700ppm
    >1MΩ0ppm to -1500ppm
    Operating Temperature-55 to +155 °C
    Lead length28mm
    Lead diameter0.55mm ±0.03mm

    Axial-0.25W/0.33W/0.5W

    A comprehensive range of high stability carbon film resistors qualified and tested to the requirements of IEC 115 and IEC 115-2. The ruggedised welded cap and lead method of manufacture provides a considerable strength and resistance to damage. The coating materials and the colour bands are epoxy resin and are highly resistant to solvents, abrasion and chipping.,Improvements in materials and processing have allowed the rated power to be improved. Excellent stability against changes in load conditions or moisture levels, with a low noise level and high reliability make these carbon film resistors suitable for a wide range of applications.,Rated at 70°C in free air mounted horizontally.,Climatic category 55/155/56.


    Specifications
    ResistanceYour Choice
    Power Rating0.25W
    Tolerance±5%
    TechnologyCarbon Film
    SeriesRS
    Temperature Coefficient-500 → +350ppm/°C
    Termination StyleAxial
    Dimensions2.3 (Dia.) x 6.3mm
    Length6.3mm
    Diameter2.3mm
    Maximum Temperature Coefficient                     +350ppm/°C
    Minimum Operating Temperature-55°C
    Minimum Temperature Coefficient-500ppm/°C
    Maximum Operating Temperature+155°C
    Lead Diameter0.55mm



    Click to view full DATASHEET

    Thank you for looking, if you have any questions please ask or call us.
