2 x Welwyn Metal Strip Resistor OAR5-R01FI 10mΩ ±1% 5W ±20ppm/°C Current Shunt - Welwyn
£0.00
£5.99
RS 366-8750
Unit Quantity:
2
Unit Type:
Unit
Location:
TS 46G
Welwyn
Welwyn OAR-5 Series Radial Metal Strip Resistor 10mΩ ±1% 5W ±20ppm/°C
- BMUK Part # :-366-8750
- BrandWelwyn
- Mfr. Part No.OAR5-R01FI
- You will get a pack of 2 Resistors

Product Details
OAR5 Series
Application: Current sensing, feedback, surge and pulse.
Inductance less than 10nH
Flameproof
Welded construction
Power at 85°C | 5W (OAR5) |
Resistance Tolerance | ±1% |
Temperature Coefficient | ±20ppm/°C |
A | 20.32 mm |
B | 25.4 mm |

Current Sense - PCB Mount / Surface Mountable
Specifications
Resistance | 10 mΩ | |
Power Rating | 5W | |
Tolerance | ±1% | |
Series | OAR-5 | |
Case Style | Metal | |
Temperature Coefficient | ±20ppm/°C | |
Termination Style | Radial | |
Dimensions | 21.97 x 1.65 x 12.08mm | |
Length | 21.97mm | |
Depth | 1.65mm | |
Height | 12.08mm | |
Minimum Temperature Coefficient | -20ppm/°C | |
Lead Pitch | 20.32mm | |
Maximum Operating Temperature | +125°C | |
Board Level Components | Y | |
Maximum Temperature Coefficient | +20ppm/°C | |
Minimum Operating Temperature | -40°C |
To view the datasheet please Click Here
