2 x Vishay High Power Metal Strip Low Ohmic Fixed Resistor 2010 Case 6mΩ 1W - Vishay

roll over the image to zoom in

£0.00
£5.99
RS 683-6117
Earn0
reward points

In stock: 57

Sorry! We're out of stock

Add To Your Wishlist
    Unit Quantity:
    2
    Unit Type:
    Unit


    Vishay

    Vishay WSL...18 High Power Series Metal Strip Low Ohmic Surface Mount Fixed Resistor 2010 Case 6mΩ ±1% 1W ±110ppm/°C



    • BMUK Part # :-  683-6117
    • BrandVishay
    • Mfr Part No.WSL20106L000FEA18
    • Vishay
    •
    • You will get 2 of












    Product Details

    2010 Format WSL...18 Series








    Surface Mount - 0508 / 0612 / 0805 / 1020 / 1206 / 1218 / 1225 / 2010 / 2512 / 2525 / 3637

    Specifications


    Length
    5mm
    Depth
    2.54mm
    Technology
    Metal Strip
    Brand
    Vishay
    Resistance
    6mΩ
    Temperature Coefficient
    ±110ppm/°C
    Dimensions
    5 x 0.7mm
    Package/Case
    2010
    Maximum Operating Temperature
    +170°C
    Minimum Operating Temperature
    -65°C
    Series
    WSL...18 High Power
    Minimum Temperature Coefficient
    -110ppm/°C
    Maximum Temperature Coefficient
    +110ppm/°C
    Height
    0.7mm
    Case Style
    Moulded
    Power Rating
    1W
    Tolerance
    ±1%
