2 x Texas Instruments SN74HC138N Decoder & Demultiplexer 1-of-8 Inverting 16-Pin - Texas Instruments
roll over the image to zoom in
£0.00
£5.99
RS 923-2486
Unit Quantity:
2
Location:
TS BRA-10F
Texas Instruments
Texas Instruments SN74HC138N, 1 Decoder & Demultiplexer, Decoder, Demultiplexer, 1-of-8, Inverting, 16-Pin PDIP
- BMUK Stock No.923-2486
- BrandTexas Instruments
- Mfr Part No.SN74HC138N
Product Details
74HC Family Decoders/Multiplexers, Texas Instruments
Texas Instruments range of Decoders, Multiplexers, Demultiplexers and Analogue Switches from the 74HC Family of CMOS Logic ICs. The 74HC Family use silicon gate CMOS technology to achieve operating speeds similar to the LSTTL family but with the low power consumption of standard CMOS integrated circuits.
74HC Family
Specifications
Maximum Operating Temperature
+85 °C
Number of Elements per Chip
1
Length
19.3mm
Number of Input Enables per Element
3
Minimum Operating Supply Voltage
2 V
Brand
Texas Instruments
Polarity
Inverting
Package Type
PDIP
Mounting Type
Through Hole
Minimum Operating Temperature
-40 °C
Width
6.35mm
Logic Family
HC
Height
4.57mm
Logic Function
Decoder, Demultiplexer
Maximum Operating Supply Voltage
6 V
Pin Count
16
Dimensions
19.3 x 6.35 x 4.57mm
Demultiplexing Capability
1-of-8
