2 x Texas Instruments MAX232IN Dual Line Transceiver RS-232 2-TX 2-RX, 5V 16-Pin - Texas Instruments
roll over the image to zoom in
£0.00
£5.49
RS 923-3906
Unit Quantity:
2
Unit Type:
Unit
Location:
TS BRA-6K
Texas Instruments
Texas Instruments MAX232IN, Dual Line Transceiver, RS-232 2-TX 2-RX, 5 V, 16-Pin PDIP
- BMUK Part # :-923-3906
- BrandTexas Instruments
- Mfr. Part No.MAX232IN
- You will get a pack of 2 ICs
Product Details
RS-232 Line Transceivers, Dual, Texas Instruments
A range of RS-232 Line Transceivers which meet or exceed the requirements of the TIA/EIA-232-F and ITU v.28 standards. These devices generally include ESD protection of up to ±15 kV (Human-Body Model), ±8 kV (Contact Discharge) and most incorporate charge pump circuitry to allow operation from single 3 V to 5.5 V supplies. Dual transceivers each contain two line drivers and two line receivers and are available with operating speeds of up to 1 Mbps.
RS-232 Line Drivers and Receivers
Specifications
| Number of Transmitters | 2 | |
| Package Type | PDIP | |
| Mounting Type | Through Hole | |
| Pin Count | 16 | |
| Number of Receivers | 2 | |
| Typical Single Supply Voltage | 5 V | |
| Data Rate | 120kbps | |
| Interface Standards | RS-232 | |
| Transmitter Signal Type | Single Ended | |
| Receiver Signal Type | Single Ended | |
| Minimum Operating Temperature | -40 °C | |
| Maximum Operating Temperature | +85 °C | |
| Power Supply Type | Single | |
| Number of Drivers per Line | 1 | |
| Number of Receivers per Line | 1 | |
| Dimensions | 19.3 x 6.35 x 4.57mm | |
| Width | 6.35mm | |
| Board Level Components | Y | |
| Height | 4.57mm | |
| Length | 19.3mm |
