2 x STMicroelectronics ULN2003A, 7-element NPN Darlington Pair, 0.5 A 50V - STMicroelectronics
£0.00
£5.49
RS 686-8209
Unit Quantity:
2
Unit Type:
Unit
Location:
TS BRA-5K
STMicroelectronics
STMicroelectronics ULN2003A, 7-element NPN Darlington Pair, 0.5 A 50 V HFE:1000, 16-Pin PDIP
- BMUK Part # :-686-8209
- BrandSTMicroelectronics
- Mfr. Part No.ULN2003A
-
- You will get a pack of 2 Transistor Drivers

Product Details
Darlington Transistor Arrays, STMicroelectronics
Darlington transistor power drivers are high-voltage, high-current switch arrays containing multiple open-collector Darlington pairs and integral suppression diodes for inductive loads. The high current rating of each output is 500 mA or higher. The inputs are pinned opposite the outputs in the IC package to simplify the application board layout. The interface is standard logic level for TTL or CMOS.
Darlington Transistor Drivers
Specifications
Transistor Type | NPN | |
Maximum Continuous Collector Current | 0.5 A | |
Maximum Collector Emitter Voltage | 50 V | |
Package Type | PDIP | |
Mounting Type | Through Hole | |
Pin Count | 16 | |
Transistor Configuration | Common Emitter | |
Number of Elements per Chip | 7 | |
Minimum DC Current Gain | 1000 | |
Maximum Collector Emitter Saturation Voltage | 1.6 V | |
Height | 5.1mm | |
Dimensions | 20 x 7.1 x 5.1mm | |
Length | 20mm | |
Width | 7.1mm | |
Board Level Components | Y | |
Maximum Operating Temperature | +85 °C | |
Minimum Operating Temperature | -20 °C |
To view the datasheet please Click Here
