2 x STMicroelectronics STP140NF75 N-channel MOSFET, 120A, 75V STripFET II, 3-Pin - STMicroelectronics
roll over the image to zoom in
£0.00
£7.49
RS 687-5302
Unit Type:
Unit
Location:
TS BRA-7M
STMicroelectronics
STMicroelectronics STP140NF75 N-channel MOSFET, 120 A, 75 V STripFET II, 3-Pin TO-220
- BMUK Part # :-687-5302
- BrandSTMicroelectronics
- Mfr Part No.STP140NF75
-
- You will get a pack of 2 Transistors
Product Details
N-Channel STripFET™ II, STMicroelectronics
STripFET™ MOSFETs with a wide breakdown voltage range offer ultra-low gate charge and low on-resistance.
MOSFET Transistors, STMicroelectronics
Specifications
Maximum Operating Temperature
+175 °C
Number of Elements per Chip
1
Length
10.4mm
Transistor Configuration
Single
Typical Turn-On Delay Time
30 ns
Brand
STMicroelectronics
Typical Turn-Off Delay Time
130 ns
Maximum Continuous Drain Current
120 A
Package Type
TO-220
Maximum Power Dissipation
310 W
Series
STripFET II
Mounting Type
Through Hole
Minimum Operating Temperature
-55 °C
Width
4.6mm
Maximum Gate Threshold Voltage
4V
Minimum Gate Threshold Voltage
2V
Height
9.15mm
Maximum Drain Source Resistance
8 mΩ
Maximum Drain Source Voltage
75 V
Pin Count
3
Dimensions
10.4 x 4.6 x 9.15mm
Category
Power MOSFET
Typical Gate Charge @ Vgs
160 nC @ 10 V
Transistor Material
Si
Channel Mode
Enhancement
Typical Input Capacitance @ Vds
5000 pF@ 25 V
Channel Type
N
Maximum Gate Source Voltage
-20 V, +20 V
