2 x STMicroelectronics OTP EPROM Memory 512kbit M27C512-10C6, 4.5-5.5V PLCC - STMicroelectronics
£0.00
£7.99
RS 686-2488P
Unit Quantity:
2
Unit Type:
Unit
Location:
TS BRA 7N AND ANOTHER
STMicroelectronics
STMicroelectronics M27C512-10C6, UV Erasable EPROM Memory 512kbit 64K x 8 bit 100ns 4.5 → 5.5 V 32-Pin PLCC
- BMUK Part # :-686-2488P
- BrandSTMicroelectronics
- Mfr. Part No.M27C512-10C6
-
- You will get 2 OTP Eproms

Product Details
EPROM (One Time Programmable), STMicroelectronics
EPROM OTP (One Time Programmable)
These EPROM (Erasable Programmable Read-Only Memory) devices contain the same chips and are programmed in the same way as their UV-eraseable counterparts. However as the package contains no window, they cannot be erased and re-programmed.
Specifications
Memory Size | 512kbit | |
Organisation | 64K x 8 bit | |
Interface Type | Parallel | |
Maximum Random Access Time | 100ns | |
Programming Voltage | 12.75V | |
Reprogramming Technique | OTP | |
In System Programmability | External | |
Mounting Type | Surface Mount | |
Package Type | PLCC | |
Pin Count | 32 | |
Dimensions | 14.05 x 11.51 x 2.8mm | |
Height | 2.8mm | |
Length | 14.05mm | |
Maximum Operating Supply Voltage | 5.5 V | |
Minimum Operating Temperature | -40 °C | |
Maximum Operating Temperature | +85 °C | |
Minimum Operating Supply Voltage | 4.5 V | |
Typical Operating Supply Voltage | 5 V | |
Width | 11.51mm |
To view the datasheet please Click Here
