2 x STMicroelectronics LF347N, Quad Op Amp, 4MHz, Dual Rail Supply 14-Pin PDIP - STMicroelectronics
roll over the image to zoom in
£0.00
£8.99
RS 356-4456
Unit Quantity:
2
Unit Type:
Unit
Location:
ES WS-4C
STMicroelectronics
STMicroelectronics LF347N, Quad Op Amp, 4MHz, 14-Pin PDIP
- You will get a pack of 2 Op Amps,
Mfr. Part No.STMicroelectronics LF347N-
Product Details
LF347, LF351, LF353, JFET Inputs, Low Input Bias & Offset Current Operational Amplifiers
The LF347, LF351 and LF353 are high-speed JFET input operational amplifiers that incorporate matched, high-voltage JFET and bipolar transistors. They feature high slew rates, low input bias and offset currents, and low offset voltage temperature coefficient.
Operational Amplifiers, STMicroelectronics
Specifications
| Mounting Type | Through Hole | |
| Package Type | PDIP | |
| Power Supply Type | Dual | |
| Number of Channels per Chip | 4 | |
| Pin Count | 14 | |
| Typical Gain Bandwidth Product | 4MHz | |
| Typical Slew Rate | 16V/µs | |
| Minimum Operating Temperature | 0 °C | |
| Maximum Operating Temperature | +70 °C | |
| Height | 5.1mm | |
| Length | 20mm | |
| Typical Input Voltage Noise Density | 15nV/√Hz | |
| Width | 7.1mm | |
| Typical Voltage Gain | 106.02 dB | |
| Dimensions | 20 x 7.1 x 5.1mm |
