2 x STMicroelectronics BTB16-600BW TRIAC 600V 16A Gate Trigger 1.3V 50mA TO-220 - STMicroelectronics

roll over the image to zoom in

£0.00
£5.99
RS 251-2909
Earn0
reward points

In stock: 160

Sorry! We're out of stock

Add To Your Wishlist
    Unit Quantity:
    2
    Unit Type:
    Unit
    Location:
    TS BRA-4K


    STMicroelectronics



    STMicroelectronics, BTB16-600BW, TRIAC, 600V, Gate Trigger 1.3V 50mA, 3-Pin TO-220AB


    • You will get a pack of 2 Triacs,
    •
    • BMUK Part # :-251-2909
    • BrandSTMicroelectronics
    • Mfr. Part No.BTB16-600BW
    •  STMicroelectronics

    STMicroelectronics, BTB16-600BW, TRIAC, 600V, Gate Trigger 1.3V 50mA, 3-Pin TO-220AB










    Product Details

    TRIAC, 16A to 20A, STMicroelectronics



    https://uk.rs-online.com/largeimages/L262028-01.gif



    TRIACs

    A range of TRIACs (Triodes for Alternating Current is also known as Bidirectional Thyristors). They are used in AC switching and control applications with current ratings from under 1A to 40A rms. A TRIAC makes a convenient switch for alternating current circuit.

    Specifications

    Mounting TypeThrough Hole
    Package TypeTO-220AB
    Maximum Gate Trigger Current50mA
    Repetitive Peak Reverse Voltage600V
    Surge Current Rating168A
    Pin Count3
    Maximum Gate Trigger Voltage1.3V
    Repetitive Peak Forward Blocking Voltage600V
    Maximum Holding Current50mA
    Dimensions10.4 x 4.6 x 9.3mm
    Length10.4mm
    Width4.6mm
    Height9.3mm
    Maximum Operating Temperature+125 °C
    Minimum Operating Temperature-40 °C
    Repetitive Peak Off-State Current0.005mA
    Peak On-State Voltage1.55V
    To view the datasheet please click here
