2 x Panasonic EETEE2D801KJ 800uF 200V DC Electrolytic Aluminium Capacitor - Panasonic

roll over the image to zoom in

£0.00
£8.99
RS 711-8202 / TS 49P + TSB-11C + TS?
Earn0
reward points

In stock: 24

Sorry! We're out of stock

Add To Your Wishlist
    Unit Quantity:
    2
    Unit Type:
    Unit
    Location:
    TS 49P + TSB-11C + TSB-10C


    Panasonic

    Panasonic 800μF Electrolytic Aluminium Electrolytic Capacitor 200V dc, Through Hole - EETEE2D801KJ

    • BMUK Stock No.711-8202
    • BrandPanasonic
    • Mfr Part No.EETEE2D801KJ
    •
    • You will get TWO capacitors
    Panasonic 800μF Electrolytic Aluminium Electrolytic Capacitor 200V dc, Through Hole - EETEE2D801KJ
    Product Details

    Highly reliable capacitors with high ripple currents and low profile
    10mm printed circuit board pitch
    Suitable for switched mode power supplies







    Specifications
    Voltage
    200V dc
    Technology
    Electrolytic
    Mounting Type
    Through Hole
    Brand
    Panasonic
    Dimensions
    30 (Dia.) x 30mm
    Capacitance
    800µF
    Diameter
    30mm
    Maximum Operating Temperature
    +105°C
    Minimum Operating Temperature
    -40°C
    Series
    EE SNAP IN
    Height
    30mm
    Ripple Current
    3.48A
    Lead Pitch
    10mm
    Lifetime
    3000h
    Tolerance
    ±20%
    Equivalent Series Resistance
    311mΩ
