2 x OUAZ-SH-112L, SPDT PCB Mount Signal Relay 12V DC Coil, 1A 120VAC 24VDC - TE Connectivity

roll over the image to zoom in

£0.00
£5.99
RS 511-7406
Earn0
reward points

In stock: 231

Sorry! We're out of stock

Add To Your Wishlist


    TE Connectivity

    2 x OUAZ-SH-112L, SPDT PCB Mount Non-Latching Relay, 12V DC




    • You will receive 2 relays
                    • BrandTE Connectivity
                    • Mfr. Part No.OUAZ-SH-112L
                    • TE Connectivity
                    SPDT PCB Mount Non-Latching Relay, 12V dc

                    Product Details

                    QUAZ Series

                    PCB Signal relay
                    Fully sealed design
                    Operating temperature -30 to +75°C
                    Dimensions H 11.2mm, W 10.4mm, D 15.4mm

                    Approvals

                    UL, CSA

                    TE Connectivity

                    Specifications
                    ApplicationCompact
                    Coil Resistance700 Ω
                    Coil Voltage12V dc
                    Contact ConfigurationSPDT
                    Contact MaterialGold Clad Silver Palladium
                    Depth10.4mm
                    Dimensions15.1 x 10.4 x 11.2mm
                    Height11.2mm
                    Length15.4mm
                    Maximum Operating Temperature+75°C
                    Maximum Switching Power AC120 VA
                    Maximum Switching Power DC30 W
                    Minimum Operating Temperature-30°C
                    Mounting TypePCB
                    Operating Temperature Range-30 → +75°C
                    Terminal TypeThrough Hole






















































































    For a Specification PDF Please     CLICK HERE


    Thank you for looking, if you have any questions please ask or call us.


    Please see our other items for a wide range of Electronic components.
