2 x ON Semiconductor NTD5862N-1G N-channel MOSFET, 98A, 60V, IPAK - ON Semiconductor
roll over the image to zoom in
£0.00
£5.99
RS 802-1036
Unit Quantity:
2
Unit Type:
Unit
Location:
TS BRA-3H PLUS ANOTHER TUBE
ON Semiconductor
ON Semiconductor NTD5862N-1G N-channel MOSFET, 98 A, 60 V, 3-Pin IPAK
- BMUK Part # :-802-1036
- BrandON Semiconductor
- Mfr. Part No.NTD5862N-1G
-
- You will get a pack of 2 Transistors
Product Details
N-Channel Power MOSFET, 60V, ON Semiconductor
MOSFET Transistors, ON Semiconductor
Specifications
| Channel Type | N | |
| Maximum Continuous Drain Current | 98 A | |
| Maximum Drain Source Voltage | 60 V | |
| Maximum Drain Source Resistance | 5.7 mΩ | |
| Maximum Gate Threshold Voltage | 4V | |
| Maximum Gate Source Voltage | ±20 V | |
| Package Type | IPAK | |
| Mounting Type | Through Hole | |
| Transistor Configuration | Single | |
| Pin Count | 3 | |
| Channel Mode | Enhancement | |
| Category | Power MOSFET | |
| Maximum Power Dissipation | 115 W | |
| Minimum Operating Temperature | -55 °C | |
| Typical Gate Charge @ Vgs | 82 nC @ 10 V | |
| Typical Input Capacitance @ Vds | 5050 pF @ 25 V | |
| Typical Turn-Off Delay Time | 35 ns | |
| Number of Elements per Chip | 1 | |
| Width | 6.22mm | |
| Height | 2.38mm | |
| Maximum Operating Temperature | +175 °C | |
| Length | 6.73mm | |
| Transistor Material | Si | |
| Dimensions | 6.73 x 6.22 x 2.38mm | |
| Typical Turn-On Delay Time | 18 ns |
To view the datasheet please Click Here
