2 x Infineon SPD06N60C3 N-channel MOSFET, 6.2A, 650 V CoolMOS C3, 3-Pin TO-252 - Infineon

roll over the image to zoom in

£0.00
£5.99
RS 753-3181
Earn0
reward points

In stock: 495

Sorry! We're out of stock

Add To Your Wishlist
    Unit Quantity:
    2
    Unit Type:
    Unit
    Location:
    TS-LB 4G


    Infineon



    Infineon SPD06N60C3 N-channel MOSFET, 6.2 A, 650 V CoolMOS C3, 3-Pin TO-252


    • BMUK Part # :-753-3181
    • BrandInfineon
    • Mfr. Part No.SPD06N60C3
    •  Infineon
    •
    • You will get a pack of 2 Transistors


    Infineon SPD06N60C3 N-channel MOSFET, 6.2 A, 650 V CoolMOS C3, 3-Pin TO-252





    Product Details

    Infineon CoolMOS™C3 Power MOSFET


    MOSFET Transistors, Infineon

    Infineon offers a large and comprehensive portfolio of MOSFET devices which includes the CoolMOS, OptiMOS and StrongIRFET families. They deliver best-in-class performance to bring more efficiency, power density and cost effectiveness. Designs requiring high quality and enhanced protection features benefit from AEC-Q101 industry standards Automotive qualified MOSFETs.


    Specifications

    Channel TypeN
    Maximum Continuous Drain Current6.2 A
    Maximum Drain Source Voltage650 V
    Maximum Drain Source Resistance750 mΩ
    Maximum Gate Threshold Voltage3.9V
    Minimum Gate Threshold Voltage2.1V
    Maximum Gate Source Voltage-20 V, +20 V
    Package TypeTO-252
    Mounting TypeSurface Mount
    Pin Count3
    Transistor ConfigurationSingle
    Channel ModeEnhancement
    CategoryPower MOSFET
    Maximum Power Dissipation74 W
    Dimensions6.73 x 6.22 x 2.41mm
    Height2.41mm
    Typical Turn-On Delay Time7 ns
    Typical Input Capacitance @ Vds620 pF @ 25 V
    Minimum Operating Temperature-55 °C
    Typical Gate Charge @ Vgs24 nC @ 10 V
    Transistor MaterialSi
    SeriesCoolMOS C3
    Maximum Operating Temperature+150 °C
    Typical Turn-Off Delay Time52 ns
    Length6.73mm
    Number of Elements per Chip1
    Width6.22mm
