2 x Epcos B32924 3.3uF Polypropylene Film Capacitor 305V AC ±20% X2 Class RFI - Epcos
roll over the image to zoom in
£0.00
£7.99
RS 497-4157
Type:
Film Capacitor
Unit Quantity:
4
Capacitor Construction:
Polypropylene Film
Location:
ES CB Box
Series:
B32924
Epcos
Epcos B32924 3.3μF Polypropylene Film Capacitor 305 V ac ±20%, Through Hole
You will get a pack of 2 Capacitors
- AC Mains 240V X2 Class rated
- Brand Epcos
- Mfr. Part No.B32924C3335M
Product Details
B32921...B32926 Series
EMI suppression capacitors (MKP) X2 class
Very small dimensions
Self-healing properties
Plastic case, epoxy resin sealing (UL 94 V-0)
"Across the line" applications
X Class X2
X Class - X2
Warning
- Capacitors X class are designed for connecting directly across a mains supply, but should NOT be used in positions where failure of a capacitor would expose anybody to electric shock.
Specifications
| Capacitance | 3.3µF | |
| Depth | 18mm | |
| Dielectric | PP | |
| Dimensions | 31.5 x 18 x 27.5mm | |
| Height | 27.5mm | |
| Lead Diameter | 0.8mm | |
| Lead Pitch | 27.5mm | |
| Length | 31.5mm | |
| Maximum Operating Temperature | +105°C | |
| Minimum Operating Temperature | -40°C | |
| Mounting Type | Through Hole | |
| Series | B32924 | |
| Tolerance | ±20% | |
| Tolerance Minus | -20% | |
| Tolerance Plus | +20% | |
| Voltage | 305 V ac |
Click to view the TECHNICAL DATA
