2 x Bourns 3386P-1-202LF, Trimmer Resistor with Pin Terminations, 2kΩ ±10% 1/2W - Bourns
roll over the image to zoom in
£0.00
£5.99
RS 522-2738
Unit Quantity:
2
Unit Type:
Unit
Bourns
Bourns 3386P Series Through Hole Cermet Trimmer Resistor with Pin Terminations, 2kΩ ±10% 1/2W ±100ppm/°C Top Adjust
- BMUK Part # :-522-2738
- BrandBourns
- Mfr. Part No.3386P-1-202LF
-
- You will get a pack of 2 Resistors
Product Details
3386P Top Adjust
Single Turn 10mm Cermet
Bourns® 3386 3/8" Square Single Turn Cermet Trimming Potentiometer (Trimpot®)
Wide choice of styles including finger adjust
Sealed to withstand immersion board washing
Moulded body with built-in PCB stand-offs
| Power At 70°C | 0.5W | Operating Torque | 5.0 oz.in. |
| Resistance Tolerance | ±10% | Rotational Life | 200 Cycles |
| Operating Voltage Maximum | 300 | Operating Temperature | -55°C → +125°C |
| Temperature Coefficient | ±100ppm/°C | Contact Resistance Variation | 2% or 3Ω (Whichever is greater) |
| End Resistance | 2Ω | Dimensions | 9.53 x 9.53 x 4.83 mm |
| Electrical Rotation (Nominal) | 280° | Pin diameter | 0.5mm |
| Mechanical Rotation (Nominal) | 310° | Linear Or Logarithmic | Linear |
Specifications
| Maximum Resistance | 2 kΩ | |
| Number of Turns | 1 | |
| Mounting Type | Through Hole | |
| Power Rating | 1/2W | |
| Series | 3386P | |
| Orientation | Top Adjust | |
| Termination Style | Pin | |
| Length | 9.53mm | |
| Depth | 9.53mm | |
| Height | 4.83mm | |
| Dimensions | 9.53 x 9.53 x 4.83mm | |
| Shaft Diameter | 3.15 mm | |
| Tolerance | ±10% | |
| Maximum Operating Temperature | +125°C | |
| Minimum Operating Temperature | -55°C | |
| Temperature Coefficient | ±100ppm/°C |
For a Specification PDF Please CLICK HERE
