2 x Bourns 3296X Series 25-Turn Through Hole Trimmer Resistor 10Ω ±10% 1/2W - Bourns
roll over the image to zoom in
£0.00
£7.99
RS 521-9833
Unit Quantity:
2
Unit Type:
Unit
Location:
BRA 11D
Bourns
Bourns 3296X Series 25-Turn Through Hole Trimmer Resistor with Pin Terminations, 10Ω ±10% 1/2W ±100ppm/°C Side Adjust
- BMUK Part # :-521-9833
- BrandBourns
- Mfr. Part No.3296X-1-100LF
-
- You will get a pack of 2 Resistors
Product Details
Side Adjust 3296X Series
Bourns® 3296X Series 3/8" Square Multiturn Cermet Trimming Potentiometer (Trimpot®)
Slim body profile - higher packing density
Sealed to withstand immersion board washing
Moulded body with built-in stand-offs
Large screw slot for easier adjustment
Wiper idles at end travel
Slim body profile-higher packing density
Sealed to withstand immersion board washing
Flame retardant plastic housing
Double chevron shaft seal
Moulded body with built in stand offs
IC style pins for PCB assembly
Precious metal wiper for set point stability
| Power | 0.5W | Operating Temperature | -55 → +125°C |
| Effective Travel (Nominal) | 25 turns | Contact Resistance Variation (Maximum) | 1% or 1Ω (whichever is greater) |
| Resistance Tolerance | ±10% | Dimensions (vertical types W Y and X) | 10 x 9.52 x 4.83 mm |
| Voltage Maximum | 300V | Dimensions (horizontal type P) | 4.83 x 9.52 x 10.03 mm |
| Temperature Coefficient | 0 to +250ppm/°C (<100Ω), ±100ppm/°C (>100Ω) | Lead Pitch | 2.54 mm |
| End Resistance | 2 Ω | Pins | 0.51 ± 0.03 mm |
| Operating Torque | 35 mNm | Linear Or Logarithmic | Linear |
| Rotational Life | 200 cycles |
| Power rating | 0.5W | Operating Temperature | -55 to 150°C |
| Voltage Maximum | 300V | End resistance | 2 Ω max |
| Effective Travel (Nominal) | 25 turns nom. | Contact resistance variation | 1% or 1Ω (whichever is greater) |
| Resistance Tolerance | ±10% | Linear or Logarithmic | Linear |
| Temperature Coefficient | ±100ppm/°C | Lead Pitch | 2.54 mm |
| Operating Torque | 35 mNm | Pins | 0.51 x 0.03 mm |
| Rotational Life | 200 cycles | Dimensions | 10 x 9.52 x 4.83 mm |
Specifications
| Maximum Resistance | 10 Ω | |
| Number of Turns | 25 | |
| Mounting Type | Through Hole | |
| Power Rating | 1/2W | |
| Series | 3296X | |
| Orientation | Side Adjust | |
| Termination Style | Pin | |
| Length | 11.05mm | |
| Depth | 4.83mm | |
| Height | 10.03mm | |
| Dimensions | 11.05 x 4.83 x 10.03mm | |
| Shaft Diameter | 2.19 mm | |
| Tolerance | ±10% | |
| Minimum Operating Temperature | -55°C | |
| Temperature Coefficient | ±100ppm/°C | |
| Maximum Operating Temperature | +125°C |
