1x Vishay VS-GBPC3512W Bridge Rectifier, 35A 1200V, 4-Pin GBPC-W Power Supply - Vishay
roll over the image to zoom in
£0.00
£13.99
RS 395-4461
Type:
Bridge Rectifier
Series:
GBPC
Peak Reverse Repetitive Voltage:
1200 V
Vishay
Vishay VS-GBPC3512W, Bridge Rectifier, 35A 1200V, 4-Pin GBPC-W
- You will get ONE Bridge Rectifier,
- BMUK Part # :-395-4461
- BrandVishay
- Mfr. Part No.VS-GBPC3512W
-
Product Details
Bridge Rectifiers for PCB Mounting, VS-GBPC35xxW Series, Vishay Semiconductor
Suitable for Printed Circuit Board (PCB) or chassis mounting
Compact construction with center hole fixing
Low thermal resistance
Wire lead structure
Approvals
UL E54214
Bridge Rectifiers - Vishay Semiconductor
The Bridge Rectifier converts an Alternating Current (AC) input into a Direct Current (DC) output for full-wave rectification applications. The diode arrangement provides the same polarity of output for either polarity of input. A three-phase full-wave rectifier is an arrangement of six diodes in a bridge circuit configuration. The packages are designed for minimal size, highest reliability and maximum thermal performance.
Specifications
| Bridge Type | Single Phase | |
| Peak Average Forward Current | 35A | |
| Peak Reverse Repetitive Voltage | 1200V | |
| Mounting Type | Through Hole | |
| Package Type | GBPC-W | |
| Pin Count | 4 | |
| Configuration | Single | |
| Peak Non-Repetitive Forward Surge Current | 400A | |
| Maximum Operating Temperature | +150 °C | |
| Minimum Operating Temperature | -55 °C | |
| Peak Forward Voltage | 1.1V | |
| Peak Reverse Current | 5µA | |
| Length | 28.8mm | |
| Width | 28.8mm | |
| Height | 7.62mm | |
| Dimensions | 28.8 x 28.8 x 7.62mm |
To view the datasheet please click here
