1x TON 15-4813WI TracoPower DC-DC Converter, 18V-75V DC In, 15V DC / 1A Out, 15W - TRACOPOWER

roll over the image to zoom in

£0.00
£68.95
RS 438-278 / TSB-40D-RB9
Earn0
reward points

In stock: 1

Sorry! We're out of stock

Add To Your Wishlist
    Unit Quantity:
    1
    Unit Type:
    Unit
    Location:
    TSB-40D-RB9


    TRACOPOWER

     TON 15-4813WI TracoPower DC-DC Converter, 18V-75V DC In, 15V DC / 1A Out, 15W

    You will get ONE DC-DC Converter

    Description:
    15W open frame single output regulated isolated high performance DC-DC converters with compact design, wide input voltage range and built-in filters for output and input. Typical applications for these high performance DC-DC converters include distributed power systems, instrumentation and industrial electronics.

    High power density, ultra-miniature 27.9x23.9x8.5mm package
    Ultra-wide 4:1 input voltage range
    Regulated outputs
    Adjustable output voltage by using external resistors
    2.25kV input / output isolation
    High efficiency up to 88%
    Low ripple and noise
    Built-in filter meets EN 55022, Class A and FCC, Level A without external components
    Remote On/Off
    Over-voltage, over-load and short circuit protection
    Open frame
    Industry standard pin-out

    Note
    Derate above 60°C.
    MTBF to MIL-HDBK-217F (25°C).
    For suitable common mode choke (L1):
    TON 15-24xx : see stock number 745-1196
    TON 15-48xx : see stock number 745-1187
    Standards
    UL 60950-1, EN 60950-1, IEC 60950-1
    Approvals
    UL/cUL recognied, File E188913

    Specifications:
