     THN 30-2410 Traco Power DC-DC Converter, 3.3V DC / 7A Out, 18V-36V DC In 30W

    You will get ONE DC-DC Converter

    Description:
    The Tracopower THN 30 series is the latest generation of high performance DC/DC converters with highest power density. The product achieves 30W output power, while it comes in a metal case of ultra compact dimensions. These DC/DC converters have a wide 2:1 input voltage range and precisely regulated output voltages, even under no load conditions. Highest efficiency across load range makes the THN 30 very reliable and applicable in temperature ranges of up to 85°C. With a low input current at no load and remote On/Off control these DC/DC converters are the ideal solution for battery-operated systems. Typical applications are in mobile equipments, instrumentation, distributed power architectures in communication and industrial electronics and everywhere where space on the PCB is critical.

    Highest power density 30W converter
    Ultra compact size
    Shielded metal case with isolated base plate
    Wide 2:1 input voltage range
    Very high efficiency across full load range up to 92%
    Over temperature protection
    Operating temperature range –40°C to +80°C and up to 85°C with heat-sink
    Ultra low no load input current
    Remote On/Off control
    Output voltage adjustable
    I/O isolation voltage 1500 Vdc
    3-year product warranty

    Standards
    UL/cUL 60950-1, IEC/EN 60950-1

    Specifications:
