     THD 12-2422 Traco Power DC-DC Converter, 18V-36V DC In ±12V DC / ±500mA Out 1

    You will get ONE DC-DC Converter

    Description:
    12W single/dual output regulated isolated high performance DC-DC converters with a low profile design and DIP-24 package. These isolated high performance DC-DC converters have built-in input and output filters and an SMD design using ceramic capacitors for reliability and long life. Typical applications for these DC-DC converters include industrial electronics, instrumentation, data communication systems and battery operated equipment where there is limited space on the PCB.

    High power density, DIP-24, 31.8x20.3x10.2mm package
    Wide 2:1 input voltage range
    Regulated outputs
    1.5kV input / output isolation
    High efficiency up to 88%
    Built-in filter meets EN 55022, Class A and FCC, Level A without external components
    Remote On/Off
    Over-load and short circuit protection
    Shielded metal case with insulated baseplate
    24-pin DIP with industry standard pin-out

    Note
    Derating 2.5% per °C above 60°C.
    MTBF to BELLCORE TR-MWT-000332 Case I: 50% Stress (40°C).
    Load regulation for dual output models is for balanced load.
    For suitable common mode choke see stock number 745-1187
    Standards
    EN 60950, UL 60950, IEC 60950
    Approvals
    UL/cUL recognised, File E188913

    Specifications:
