1x TEN 3-4811 Traco Power DC-DC Converter, 36V-72V DC Input 5V DC / 500mA Output - Traco Power

roll over the image to zoom in

£0.00
£26.95
RS 217-6799 / TSB-40D-RB3
Earn0
reward points

In stock: 10

Sorry! We're out of stock

Add To Your Wishlist
    Unit Quantity:
    1
    Unit Type:
    Unit
    Location:
    TSB-40D-RB3


    Traco Power

     TEN 3-4811 Traco Power DC-DC Converter, 36V-72V DC Input 5V DC / 500mA Output

    You will get ONE DC-DC Converter

    Description:
    The Traco Power TEN 3 series is a range of isolated, 3 Watt, DC-DC converters in a DIP-24 package. With their high efficiency these regulated converters allows an operating temperature range of –40°C to +85°C. The full SMD design of these DC-DC converters guarantees high reliability. The TEN 3 series is ideal for a wide range of applications in industrial and communication systems.

    Wide 2:1 input range
    High efficiency up to 84%
    Full SMD-design
    Short circuit protection
    Extended operating temperature range –40°C to 85°C
    I/O isolation 1500 VDC
    Input filter to meet EN 55022, Class A and FCC, level A without external components
    24-pin DIP with industry standard pinout
    High reliability, MTBF >1.1 Mio. h

    Standards
    cUL/UL 60950-1, IEC/EN 60950-1
    Approvals
    cUL/UL , IEC/EN , CSA File No. 226037
    Approvals
    UL Recognised; EN60950; UL1950

    Specifications:
