1x PF0001/63 Bulgin C14 Panel Mount IEC Connector Male, 10A 250V Fuse 5mmx20mm - Bulgin
roll over the image to zoom in
£0.00
£7.95
RS 815-830 / TSB-40B-RB6
Unit Quantity:
1
Unit Type:
Unit
Location:
TSB-40B-RB6
Bulgin
PF0001/63 Bulgin C14 Panel Mount IEC Connector Male, 10A 250V Fuse 5mmx20mm
You will get ONE connector
Description:
The Bulgin IEC fused inlet is a twin fused, flanged mount, straight C14 male plug device. It has a voltage rating of 250VAC and current rating of 10A. The fuse link is an electrically connected wire directly to the plug using type 250 (0.25in) blade receptacles.
Note:
These fused plugs accept 5mm x 20mm fuses.
Warning:
Neutral line must not be fused where it is referenced to the earth.
Features & Benefits:
Interlocked fuse drawer accepts 20mm fuses
Tab terminal
Contact resistance is less than 10mΩ
Insulation resistance is greater than 1000MΩ
Operating temperature ranges between -40°C and 70°C
Applications:
Domestic appliances
Electrical appliances
Instrumentation amplifiers
Computer hard drives
Certifications:
UL approved
CSA certified
IMQ
SEMKO
VDE
Approvals:
UL recognised component, CSA certified, IMQ, SEMKO, VDE
Note:
These fused plugs accept 5mm x 20mm fuses.
Warning:
Neutral line must not be fused where it is referenced to the earth.
Features & Benefits:
Interlocked fuse drawer accepts 20mm fuses
Tab terminal
Contact resistance is less than 10mΩ
Insulation resistance is greater than 1000MΩ
Operating temperature ranges between -40°C and 70°C
Applications:
Domestic appliances
Electrical appliances
Instrumentation amplifiers
Computer hard drives
Certifications:
UL approved
CSA certified
IMQ
SEMKO
VDE
Approvals:
UL recognised component, CSA certified, IMQ, SEMKO, VDE
Specifications:
